DJ PNEUMATIC JET

DJP
DJ  PNEUMATIC JET



  • 2,5,10,20 and 30 mm displacement transducer measuring ranges
  • Accuracy better than 0.1 µm
  • Repeatability precision better than 0.05 µm
  • Resolution better than 0.01 µm
  • Range of contact sensor tips available
  • Pneumatic actuation using internal piston – gaiter independent.
  • Standard contact sensor tip force of 0.7N (other options available)
  • IP50 sealing
  • Displacement sensor with excellent sideload capability
  • Superior performance compared to traditional Linear
  • Variable Differential Transformer (LVDT) displacement sensors
  • High resistance to external magnetic fields which can interfere with measurements from typical LVDTs
  •

    Jet ‘J Type' probes are similar to pneumatic except that actuation is by an inbuilt piston. High tip forces are available but as air is vented through a port close to the front of the probe, they have a lower IP rating. These probes will continue to operate even if the gaiter becomes punctured
